TA/F-2000
CENTAURO
TECHNICAL DATA
Max. distance between centers 2000mm
Max. turning and milling diameter Ø 250 178
Max. diameter allowed on the small steady rest Ø 90 65
Max. diameter allowed on the large steady rest Ø 140 100
Tailstock quill diameter 60
Programmable carriage feed speed mt./min. 0 - 30
Variable and programmable spindle speed 0-4500 rpm.
Product specification
Year:
2007
Motor power kW:
9,5
Net weight kg:
2000
Overall dimensions mm:
4100x1380x1870
